Data
Description Symbol Unit HLT05.1W- ... -0-N-D7-NNNN
45K 105K 245K
Continuous power P
BD
kW 45 105 245
Short time power (60 s) P
BK
kW 60 145 350
Peak power (2 s) P
BS
kW 85 205 495
Minimum braking resistance R
min
Ω 5.4 2.7 1.0
Balancing factor for P
BD
(for parallel operation
at common DC bus)
f 0.95
Min. braking transistor switch-on threshold U
HLT_On_min
V 820
Max. braking transistor switch-on threshold U
HLT_On_max
V 850
Workload-based delay of braking transistor
switch-on threshold
U
HLT_On_d
V 30
Emergency comparator switch-on voltage U
Not
V 943 ±2.5%
Max. input voltage U
max
V 980
Continuous current for DC connection points I
nom
A 100 200 500
Power dissipation (full load) P
Diss_max
W 250 400 1000
Power dissipation (standby) P
Diss_min
W 20
Rated control voltage input U
N3
V 24 ±20%
Control voltage input current I
N3
mA 470 630
Short circuit current rating SCCR kA rms 85
Weight m kg 7.5 23
Tab. 8-60: HLT05, ratings
DOK-INDRV*-HXX05******-PR02-EN-P Bosch Rexroth AG 259/407
Rexroth IndraDrive ML Drive Systems with HMU05
Cables, accessories, additional components
