Bosch RH540M - Functional Description and Specifications; Tool Holder Components; Ergonomic Handles; Control Mechanisms

-7-
Model number RH540M RH540S
Shank style SDS Max Spline
Maximum Capacities:
Carbide tipped bits 1 9/16" 1 9/16"
Carbide tipped core bits 4" 4"
:3(9.43&1*8(7.59.43&3)5*(.+.(&9.438
.8(433*(9 9-* 51:, +742 9-* 54<*7 84:7(* '*+47* 2&0.3, &3>
&88*2'1>&)/:892*39847(-&3,.3,&((*8847.*8 Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
49&7>&22*7
TRIGGER
SWITCH
AUXILIARY
HANDLE
HAND GRIP
DUST
SHIELD
LOCKING
SLEEVE
SELECTOR LEVER
VENTILATION
OPENINGS
FIG. 1
SPLINE TOOL HOLDER
(Model RH540S only)
 For tool specifications refer to the nameplate on your tool.
VENTILATION
OPENINGS
VARIABLE
SPEED DIAL
BM 1619P11323 04-13_BM 1619P11323 04-13.qxp 4/23/13 7:12 AM Page 7
