Bosch Solution-16 User Manual

Location 000 – 015
Primary Telephone Number
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 016 – 031
Secondary Telephone Number
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 032 – 047
Call Back Telephone Number
(0=10 and telephone termination = 0, anywhere else 0=0)
Location 48
Dialling Format
Location 49
Handshake Tone
Location 50
Transmission Format
Location 51
Transmission Speed
Location 052 – 055
Subscriber ID Number For Area 1
Location 056 – 062
Installer Code
Location 063
Ring Count
Location 064 – 319
User Codes
User Code 1
Authority
Level
User Code 2
Authority
Level
User Code 3
Authority
Level
Location 064 - 070 071 Location 072 - 078 79 Location 080 - 086 87
2 5 8 0 15 15 15 8 15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0
User Code 4
Authority
Level
User Code 5
Authority
Level
User Code 6
Authority
Level
Location 088 - 094 095 Location 096 - 102 103 Location 104 - 110 111
15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0
User Code 7
Authority
Level
User Code 8
Authority
Level
User Code 9
Authority
Level
Location 112 - 118 119 Location 120 - 126 127 Location 128 - 134 135
15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0
User Code 10
Authority
Level
User Code 11
Authority
Level
User Code 12
Authority
Level
Location 136 - 142 143 Location 144 - 150 151 Location 152 - 158 159
15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0
User Code 13
Authority
Level User Code 14
Authority
Level User Code 15
Authority
Level
Location 160 - 166 167 Location 168 - 174 175 Location 176 - 182 183
0 0 0 0 0 0 0 0 15 15 15 15 15 15 15 0 15 15 15 15 15 15 15 0
000000000 0 0 0 0 000
000000000 0 0 0 0 000
000000000 0 0 0 0 000
1 = Australian DTMF 4 = International DTMF
2 = Australian Decadic 5 = Reversed Decadic
3 = Alternate DTMF & Decadic (Aust) 6 = Alternate DTMF & Reversed Decadic
1
1 = HI-LO Handshake (Contact ID) 4 = No Handshake
2 = 1400 Hz (Ademco TX @ 1900 Hz) 5 = Pager
3 = 2300 Hz (Sescoa TX @ 1800 Hz)
1
1 = Contact ID 6 = 4 + 1 Pulsed Expanded 11 = Domestic
2 = 4 + 2 Expressed 7 = 3 + 1 Pulsed Universal 12 = Basic Pager
3 = 4 + 2 Pulsed 8 = 3 + 1 Pulsed Expanded 13 = Reserved
4 = 4 + 2 Pulsed + Checksum 9 = Reserved 14 = PET Alpha Pager
5 = 4 + 1 Pulsed + Universal 10 = Reserved 15 = Synthesised Voice
1
1 = 1 Pulse / Second 4 = 20 Pulses / Second
2 = 10 Pulses / Second 5 = 20 Pulses / Second FDL
3 = 15 Pulses / Second 6 = 40 Pulses / Second
2
0 0 0 0
1 2 3 4 15 15 15
0 = Panel Will Not Answer 14 = Answering Machine Bypass 2 (V1.37+)
1 – 13 = No Of Rings Until Panel Answers 15 = Answering Machine Bypass 1
8
8 Solution-16/Solution-16
Safecom
Quick Reference Guide
SOL 16 SAFECOM QUICK REF GUIDE.DOC.DOC Bosch Security Systems Pty Limited
