Fig. 2 Boiler components
[1] Pressure differential switch
[2] Fan
[3] Burner head
[4] Spark electrode
[5] Circulation pump
[6] Condensate trap
[7] Return temperature probe
[8] Heat exchanger
[9] Main controller
[10] Automatic air vent
[11] High limit temp. safety switch
[12] Supply temperature probe
[13] Gas valve
[14] Low water cut off probe
