After installation
TR4000 | TR4000R – 6720876021 (2022/04)
18
3 After installation
3.1 TR4000 5 ET, TR4000 6 ET, TR4000 6 EB,
TR4000 8 ET and TR4000 8 EB
(fixed electrical connection)
Switch on the fuses.
3.2 TR4000 4 ET and TR4000R 4 ET
• Insert the plug into the mains socket.
First start-up
(Fig. 6)
3.3 Initial rinsing
• Open the warm water tap and allow water to flow for at least
1 minute (flow-rate at least 2 litres per minute). Only then
(for safety reasons) will the appliance begin to heat.
Info: The appliance will not heat if the dispensed water flow is
interrupted prematurely. Open the warm water tap again and
allow water to flow for at least 1 minute.
Tip: Should the appliance not start because of a reduced flow-
rate, remove the perlator, aerator or similar before starting and
repeating the process.
Important: If the continuous-flow heater does not have
sufficient water flow due to low water line pressure in your
domestic plumbing system:
• Switch off the circuit-breakers/fuses or remove the mains
plug.
• Remove the flow-rate limiter (H1–H4).
3.4 Controlling temperature
The supply temperature (probably lower in winter) and
pressure fluctuations can influence the temperature of the
water leaving the tap (see Fig. 4, left: pressurised [closed],
right: unpressurised [open]).
• Turn the valve slowly in the closed direction for higher
temperatures (F1).
• Add cold water for lower temperatures (F2).
• Hand over the installation and operating instructions
to the user and explain how the appliance operates.
4Technical data
Type TR4000 4
ET
TR4000R 4
ET
Undersink
TR4000 5
ET
Undersink
TR4000 6
ET
Undersink
TR4000 8
ET
Undersink
TR4000 6
EB
Over-sink
TR4000 8
EB
Over-sink
Design pressurised pressurised pressurised pressurised pressurised pressurised
Power [kW] 3,6 4,5 6 7,2 6 7,2
Electrical connection [V] 230 230 230 230 230 230
Minimum cable cross-section [mm²] 1,5 2,5 4 4 4 4
Rated current [A] 15,7 19,1 26 31,3 26 31,3
Fuse protection [A] 16 20 32 32 32 32
Water connection thread [Inch] G 3/8 G 3/8 G 3/8 G 3/8 G 1/2 G 1/2
Supply temp. max. [°C] 20 20 20 20 20 20
Warm water output at supply
temp. of 12 °C to 38 °C
[l/min] 1,9 2,4 3,2 3,9 3,2 3,9
Protection type IP 24 24 24 24 24 24
Switch on flow pressure
(without flow rate limiter)
[bar] < 0,3 < 0,3 < 0,3 < 0,3 < 0,3 < 0,3
Switch on flow [l/min] 1,8 1,8 / 1,9 1,8 / 2,1 1,8 / 2,3 1,8 / 2,1 1,8 / 2,3
Switch off flow [l/min] 1,6 1,6 / 1,7 1,6 / 2,0 1,6 / 2,2 1,6 / 2,0 1,6 / 2,2
