8 | English
Press the locking mechanism of the storage
compartment(15) inwards, open the lid(7) of the adapter
storage compartment and remove the appropriate adapter.
If present, remove the valve cap on the item to be inflated.
Winding up and Unwinding the Pressure Hose (10)
(seefigureA):
– Unwind the pressure hose(10) by releasing it from the
hose clamps(9).
– When winding up the pressure hose(10), ensure that it is
held by the hose clamps(9).
Connecting the Air Pump to the Valve (seefigureB):
– Valve adapter(13): Firstly, screw the adapter onto the
valve. Then screw the adapter fully into the pressure
hose(10).
– Ball needle adapter(14) and volume adapter(12):
Firstly, screw the adapter fully into the pressure
hose(10). Then tighten the pressure hose(10) with the
adapter in the valve.
– If no adapter is required, tighten the pressure hose(10)
on the valve.
The current pressure (bar/psi) in the connected item is
shown on the pressure gauge(1).
Inflation:
– Press the lock-off button(6) to the left (see figureC).
– Press the on/off switch(5) to switch on the air pump and
to start pumping. At the same time, the worklight(11)
and the pressure gauge lighting are switched on.
Do not look into the worklight; it can blind you.
– If the required pressure is displayed on the pressure
gauge(1), release the on/off switch(5). The
worklight(11) and pressure gauge lighting go out and the
air pump is switched off.
– Once work is complete, lock the on/off switch by pressing
the lock-off button(6) to the right (see figureC).
Note: When pumping for longer periods, stop pumping after
approximately 5 minutes and leave the hose and metal parts
of the adapter to cool for at least 5 minutes.
Maintenance and Service
Maintenance and Cleaning
u Remove the rechargeable battery from the air pump
before carrying out any work on the air pump (e.g.
maintenance, tool change, etc.) as well as when trans-
porting and storing the air pump. There is risk of injury
from unintentionally pressing the on/off switch.
u To ensure safe and efficient operation, always keep
the air pump and the ventilation slots clean.
After-Sales Service and Application Service
Our after-sales service responds to your questions concern-
ing maintenance and repair of your product as well as spare
parts. You can find explosion drawings and information on
spare parts at: www.bosch-pt.com
The Bosch product use advice team will be happy to help you
with any questions about our products and their accessor-
ies.
In all correspondence and spare parts orders, please always
include the 10‑digit article number given on the nameplate
of the product.
People’s Republic of China
China Mainland
Bosch Power Tool (China) Co. Ltd.
Bosch Service Center
567, Bin Kang Road
Bin Kang District
Hangzhou, Zhejiang Province
China 310052
Tel.: (0571) 8887 5566 / 5588
Fax: (0571) 8887 6688 x 5566# / 5588#
E-Mail: bsc.hz@cn.bosch.com
www.bosch-pt.com.cn
You can find further service addresses at:
www.bosch-pt.com/serviceaddresses
Transport
The recommended lithium-ion batteries are subject to legis-
lation on the transport of dangerous goods. The user can
transport the batteries by road without further require-
ments.
When shipping by third parties (e.g.: by air transport or for-
warding agency), special requirements on packaging and la-
belling must be observed. For preparation of the item being
shipped, consulting an expert for hazardous material is re-
quired.
Dispatch battery packs only when the housing is undam-
aged. Tape or mask off open contacts and pack up the bat-
tery in such a manner that it cannot move around in the
packaging. Please also observe the possibility of more de-
tailed national regulations.
Disposal
Air pumps, battery packs, accessories and
packaging should be sorted for environmental-
friendly recycling.
Do not dispose of air pumps and batteries/re-
chargeable batteries in household waste!
Battery packs/batteries:
Li-ion:
Please observe the notes in the section on transport (see
"Transport", page8).
1 609 92A 7AH | (25.05.2022) Bosch Power Tools
