-12-
Technical Data
Universal detector D-tect 200 C
Article number 3 601 K81 6..
Max. object detection depth
A)
– In dry concrete
• Metal objects 7.9 in (200 mm)
• Other objects 3.15 in (80 mm)
– Metal objects in early age concrete 2.36 in (60 mm)
– Wooden beams in drywalls 1.5 in (38 mm)
– Objects in horizontal coring bricks 1.96 in (50 mm)
– Objects in other supported wall types 3.15 in (80 mm)
Accuracy of object center measurement
A)
0.2 in (±5 mm)
Accuracy of indicated object depth
A)
– In dry concrete 0.2 in (±5 mm)
– In early age concrete 0.4 in (±10 mm/m)
Minimum distance between two neighbouring objects
A)
1.6 in (40 mm)
Accuracy of distance measurement
B)
0.4 in (±10 mm/m)
Radar sensor
– Operating frequency range 1.8–5.8 GHz
– Max. transmission power 0.00001 mW
Inductive sensor
– Operating frequency range 48–52 kHz
– Max. magnetic field strength (at 33 ft (10 m)) 20 dBμA/m
Max. altitude 6,561 Ft (2000 m)
Relative air humidity max. 90 %
Relative air humidity max. for "live" material identification
50 %
Pollution degree according to IEC 61010-1 2
C)
Detection tool power supply
– Rechargeable battery (Li-ion) 10.8V/12V Max
Approx. operating time
– Rechargeable battery (Li-ion)
6 h
Backup power supply for saving the time
– Button cell
CR2032 (3 V lithium battery)
– Battery life approx.
12 months
Battery Charger List
–Rechargeable Batteries
BAT414, GBA12V30
–Chargers
BC330, BC430, GAX1218V-30, GAL 12V-20
