Bosch WFMC3200UC - Page 13

2nd Edition/Revision 0 (4/28/04)
R020031E
13
/
Operation
Operation
–
–
Sensors (7)
Sensors (7)
4. Unbalanced Load Sensor
Spin speed [rpm]
0
200
400
600
800
1000
1200
max. 15 trials
III
IV
II
I
load distribution unbalance Spin speed (rpm) spinning profile
good small 1200 (max.) I
uneven medium 1000 (reduced) II
bad big 800 (low) III
none dangerous no spinning IV
After 4 attempts
After 7 attempts
After 14 attempts
2-step detection
