2nd Edition/Revision 0 (4/28/04)
R020031E
WFMC/WFXD Service Tips
WFMC/WFXD Service Tips
–
–
Test Program
Test Program
(1A): Starting WFMC32/WFXD52 Test Program
(1A): Starting WFMC32/WFXD52 Test Program
53
/
The WFMC32/WFXD52 washer test programs self-diagnose problems
, including listing the last 8
fault codes from the control module & the last 16 fault codes from the motor control. The tests are
easy to use, speeding up and simplifying diagnosing washer issues.
NOTE: Door locks
for all water fill and
drain tests.
HINT: If
Start/Pause light
doesn’t come on for
some tests, door is
open. Turn off
washer, then close
door.
Entering & using WFMC32/WFXD52 test programs:
• To reset, rotate cycle selector knob to Off position.
• To enter test program
, push and hold Spin Selection and Delay Start buttons at the same time,
then rotate cycle selector knob ccw to Permanent Press Cold position. Hold Spin Selection
and Delay Start buttons until P:01 shows in display.
• To select tests
, push Spin Selection button (to scroll through tests) until desired test shows in
display (P:01 - P:17) - Start/Pause light will flash.
• To start tests
, push Start/Pause button while its light is flashing -- light stays lit when test has
started. To end tests
, push Spin Selection button.
• To exit test program, rotate cycle selector knob to Off position.
WFMC32
P:01
