2nd Edition/Revision 0 (4/28/04)
R020031E
WFMC/WFXD Service Tips
WFMC/WFXD Service Tips
–
–
Test Program (1B):
Test Program (1B):
Starting WFMC64/WFXD84 Test Program
54
/
Starting WFMC64/WFXD84 Test Program
The WFMC64/WFXD84 washer test programs self-diagnose problems
, including listing the last 8
fault codes from the control module & the last 16 fault codes from the motor control. The tests are
easy to use, speeding up and simplifying diagnosing washer issues.
Entering & using WFMC64/WFXD84 test programs:
• To reset, rotate cycle selector knob to Off position.
• To enter test program
, push and hold Menu and Select buttons at the same time, then rotate cycle
selector knob ccw to Permanent Press Cold position. Hold Menu and Select buttons until P1:
Errors shows in display.
• To select tests
, push Menu button (to scroll through tests) until desired test shows in display (P1 -
P17) - Start/Pause light will flash.
• To start tests
, push Start/Pause button while its light is flashing -- light stays lit when test has
started. To end tests
, push Menu button.
• To exit test program, rotate cycle selector knob to Off position.
NOTE: Door locks
for all water fill and
drain tests.
HINT: If
Start/Pause light
doesn’t come on for
some tests, door is
open. Turn off
washer, then close
door.
WFMC64
P1:ERRORS
