Bosch WFMC3200UC - Page 52

2nd Edition/Revision 0 (4/28/04)
R020031E
52
120V input
2-PK
5-BK
2-BL
4-WH
7-BL
WH
GY
YE
GN
WH
PK
BL
HINT: This
will help with
reconnecting
wires.
WH
To water
valves
To pressure
switch
To door
lock
To motor
control
To drain
pump
Remove cover to access wires
WFMC64/WFXD84 Service Tips
WFMC64/WFXD84 Service Tips
–
–
Control
Control
Module Wire & Terminal Colors
Module Wire & Terminal Colors
2-BL
WH
IMPORTANT: Its
possible to miswire the
WH, GY & GN
terminals. Make sure
the terminals are in the
right order & direction
(wires on left side).
/
To heater
