2nd Edition/Revision 0 (4/28/04)
R020031E
Disassembly
Disassembly
–
–
Drum/Front Panel (1)
20
/
Drum/Front Panel (1)
Remove hinge cover screws Remove hinge screws Remove door seal spring
Remove door latch screws Carefully remove front shield Removing front shield
