Bosch WFMC3200UC - Component Ratings

2nd Edition/Revision 0 (4/28/04)
R020031E
35
/
WFMC/WFXD Service Tips
WFMC/WFXD Service Tips
–
–
Ratings (2)
Ratings (2)
• Drum motor: 120VAC, 3-phase, 850W, 400Hz variable
frequency (for use with 3-phase motor control),
asynchronous, class F insulated, with tachometer.
• Heater
: 240VAC, 1000W, 8.8A, 13.7 – 15.2
W
.
• Drain pump
: 120VAC, 60 Hz, 70W, class F insulated, 15
min. on / 45 min. off duty, thermally protected, isolated by
four rubber feet (noise/vibration dampened).
• Drain pump flow rate
: 18 liters/minute @ 2.5m (8’) head
and 30 liters/minute @ 1.25m (4’) head .
• Water levels
(cotton cycle, empty drum):
• 1
st
: 1 – 1.6 gal. (4 – 6 l); ~ 1.7” – 2.5” (43 – 65mm)
• 2
nd
: 4 – 4.5 gal. (15 – 17 l); ~ 4.5” – 5.1” (115 – 230mm)
• Overflow: 15 gal. (57 l); ~ 10.6” – 11.4” (270 – 290mm)
