WFMC/WFXD Service Tips
WFMC/WFXD Service Tips
–
–
Drain Pump
Drain Pump
Drain pumps reliably pump water out from washer
tubs through the drain reservoir and drain hose.
Unlike earlier washers, these pumps are
maintenance free -- access to remove debris is
only meant for servicers.
HINT: Drain pumps are mounted on four rubber
feet to dampen vibration & noise. To remove
drain pumps, carefully slide them toward rear of
washers. To install them, carefully insert all four
feet into notches in washer base, then slide
them forward.
NOTE: Drain pump motor resistance ranges from
140 – 200
. Its rated @ 120VAC, 60 Hz, 70W.
HINT: To remove the drain pump access cover,
insert a pointed object (or tool) into the hole, push in
to release the latch and rotate the cover clockwise.
NOTE: There’s no provision for draining residual water from drain pumps.
Current production pumps are beige
color – earlier WFMC pumps were black.
