There is a retainer latch (“catch”) in both the left and right sides so
there’s no need to move them.
8) Remove hinge from right side of dryer by removing two (2) screws
and lifting the hinge up and away from the dryer. Move hinge to
left side of dryer and attach with two (2) screws. Make sure plastic
hinge bushings don’t fall off.
9) Reinstall front panel latch cover on the right side of the dryer with
(2) screws.
10) Place door onto hinge and reinstall door hinge cover with four (4)
screws to secure door to dryer.
5.1.10 Rear panel
Remove top panel (5.1.1) for better access to parts. Remove two T-
10 Torx screws holding rear panel to rear exhaust vent. Remove T-20
Torx screws holding rear panel to frame and to power connection
sheet. Lift panel out.
Two power connection sheet
screws.
Rear panel access is best for most repairs.
702_58300000143767_ara_en_a Page 20 of 33
