6
English
2.4 Attaching the speaker to the bracket
Partially insert the screws into the speaker, but do not fully tighten
them. Then slide the speaker onto the bracket and hand tighten the
two screws.
2.3 Connecting the amplifier wires
Be sure to observe polarity as you connect the amplifier wires.
Attach the positive lead to the positive terminal, directly opposite the
terminal with the orange (for 70V) or yellow (for 100V) wire attached.
Installation
