Bose 701 Series II - Technical Specifications and Features; Customer Service and Cleaning

AM257817_00_V.pdf October 25, 2001 11
Reference Information
Technical Information
Power rating
USA/Canada: 120V ~ 50/60 Hz, 260 W
Europe/Australia: 220-240V ~ 50/60 Hz, 260 W
Features
• Direct/Reflecting
®
speaker technology
• Stereo Everywhere
®
speaker technology
• Automatic protection circuitry
• Syncom
®
computer quality control
Speaker driver complement
• One 8" (20.3 cm) woofer per cabinet
• One 6
1
⁄
2
" (16.5 cm) mid-range driver per cabinet
• One 2" (5.1 cm) ferrofluid-cooled tweeter
• One 3" (7.6 cm) tweeter per cabinet
Compatibility
Compatible with A/V receivers and amplifiers rated from 10 to 300 watts per channel, rated
from 4 to 8 ohms.
Finish
• Deep charcoal
• Natural wood grain
Dimensions/Weight
39"H x 8"W x 16
1
⁄
2
"D (99 cm x 20 cm x 42 cm)
Left main speaker is 50 lb (22.7 kg); right accessory speaker is 45 lb (20.4 kg)
Wire recommendations
Based on maximum frequency response deviation of 0.5 dB
Customer service
For additional help in solving problems, contact Bose
®
customer service. See the enclosed
list of Bose customer service offices and phone numbers.
Cleaning
Wipe the 701
®
speaker cabinets using a dry cloth. Do not use solvents or chemicals. Do not
allow liquids to spill on or objects to drop into the speaker grilles. You may vacuum the grilles
carefully; the drivers are directly behind the grille cloth. No other maintenance is needed.
Gauge Length
18 (0.82 mm
2
)
20 ft (6 m) maximum
16 (1.3 mm
2
)
30 ft (9 m) maximum
14 (2.1 mm
2
)
50 ft (15 m) maximum
12 (3.3 mm
2
)
80 ft (24 m) maximum
