6
Specifications
PART LIST NOTES
1. The individual parts located on the PCBs are listed in the Electrical Part List.
2. This part is referenced for informational purposes only. It is not stocked as a repair part.
Refer to the next higher assembly for a replacement part.
3. This part is critical for safety purposes. Failure to use a substitute replacement with
the same safety characteristics as the recommended replacement part might create shock,
fire and/or other hazards.
System Performance
System Type Two-way
Frequency Response (-3 dB) 56 Hz - 16 kHz
Frequency Range (-10 dB) 47 Hz - 20 kHz
Nominal Dispersion 100° H x 40° V (C-position)
Maximum SPL @ 1 m 121 dB SPL (127 dB SPL peak)
Sensitivity (SPL / 1 W @ 1 m) 95 dB SPL
Long-term Power Handling 400 W (1600 W peak)
Nominal Impedance 8Ω
Tranducers
Driver Compliment 8 x 2.25” mid-high drivers; 1 x 12” LF driver
Physical
Connectors
(2) parallel-wired NL4 Neutrik
®
Speakon
®
connectors, four-terminal barrier strip up to 12 gauge speaker wire
Suspension/Mounting 6 x M8 threaded inserts, 1 x 1-3/8” (35 mm ) pole mount
Enclosure High impact composite materials
Grille Powder-coated perforated steel grille
Dimensions (H x W x D) 664.66 mm x 334.3 mm x 372.5 mm (26.1” x 13.1” x 14.6”)
Net Weight 21.31 kg (47 lbs)
