Bass Module Parts List (Figure 4)
25
Item
Number
Description Part Number Qty.
Per
Module
See Note
1 Panel Assembly-120V 145530-1 1 1,2
Panel Assembly-230V 145530-2 1 1,2
Panel Assembly-100V 145530-3 1 1,2
2 Screw-HIRS,8-10x1,PAN,XREC/SQ 137527-16 20
3 Screw-Mach.,1/4 x 20,Hex Wshr. Hd. 148658 2 5
4 Cover-Rod 145983 2
5 Strap-Mounting,Black 145554-01 2
Strap-Mounting,White 145554-02 2
6 Cover-Terminal Block,Yellow 147524-32 1
7 Box-Junction,Black 145107-01 1
8 Cover-Junction Box 145108-01 1
9 Screw-Tapp,8-32 x 9/16,PAN,XRC 145727-09 4
10 Nut-Hex,Stnd.,Washer,KEPS 118260-08 4
11 Bushing-Rubber 146046 2 7
12 Plate-Anti-rotation 146047 1 7
13 Bushing-Strain relief 146048 1 7
14 Power Transformer-EI96,100/120V,T2
or
145526 1 6
Power Transformer (alternate),T2
135964 1 6
Power Transformer-220/240V,T2
137819 1 6
15 Nut-Hex,M5 137448 4
16 Washer-M5 138513 4
17 Isolator-Vibration 140343 4
18 Cable Tie 135540 1
!
To Next Page
