Bose FREESPACE BUSINESS - Page 45

44
Connectors
Reference
Designator
Description Part Number See Note
P1,2,4 Header-Right
Angle,2 pin,4.0mm
134290-02
P3 Header-Right
Angle,4 pin,2.5mm
145402-04
N/A Housing Assy.,
2+2 pin,210mm,
Left channel
171322
N/A Housing Assy.,
2+2 pin,265mm,
Right channel
171323
J101 Header-7 pin,
I-type,B7B-XH-A
141792
J201 Housing Assy.,
4+4 pin,445mm
171324
J201 Header-4 pin,
I-type,B4B-XH-A
141790
J301-303 Header-2 pin,
I-type,B2P-VH
141787
J401 Header-2 pin,
I-type,LB02TV
141788
J402 Header-3 pin,
I-type,STV-8-3W
171325
J403 Header-5 pin,
I-type,STV-8-5W
141791
J501 Connector Assy.,-
7 pin,300mm
141816
J502 Header-2 pin,
L-type,B2PS-VH
171332
Miscellaneous Components
Reference
Designator
Description Part Number See Note
K1
or
Relay-
10A24VDC,250V,
SPST,VS-24MB-
VD3
10A,240V,
MX1-24D-A01,1P1T
171326 6
L1,2 Inductor-0.5mH,
10%
145725
R8 Potentiometer-
Dual,2K,Detent
149281
!
