46
Main PCB Assembly Mechanical Parts List
NOTE
The parts given in this list are not illustrated. However,the description column provides
location information for these parts.
Item
Number
Description Part Number Qty. See Note
- Fuse Holder-5x20 mm
[F1]
171334 2
- Heatsink
[REG1 and REG2 are attached to it]
141661 2 1
- Heatsink Coupler (Double)
[Has 12 transistors attached to it]
141271 1 1
- Heatsink Coupler (Single)
[Has 6 transistors attached to it]
141272 1 1
- Heatsink (B)
[Z401 and Z402 are attached to it]
141274 1 1
- Screw-Machine,M3x6x0.5 B/H,Zinc
Plated
[Secures REG1 and REG2 to heatsinks]
171624 2
- Screw-3x12 B/H, ZN H.S.
[Secures Z401 and Z402 to black heatsink]
141284 2
- Screw-3x8 B/H H.S. BK
[Secures 18 transistors to heatsink couplers
and secures the black heatsink to the PCB]
141285 20
- Screw-3x6 BH S.T.
[Secures both heatsink couplers to PCB at the
ends of each coupler]
141283 4
To Next Page
