Bose FreeSpace DS 16F Datasheet

FreeSpace
®
DS 16F
Loudspeaker
Driver complement:
One2.25"(57mm)full-rangedriver
Construction features:
•Enclosure:PC/ABS
•Grille:Powder-coatedsteel
•Integralquick-installmountingfeatures
•Threemountingpointsattherearofthe
housing for pendant mounting
Dimensions:
Outerflangediameter:9.4"(239mm)
Ceilingholediameter:8"(203mm)
Heighttotopofhousing:6.2"(158mm)
Weight:
Product:4.4lb(1.9kg)
Shipping: 6lb (2.7kg)
Package contents:
Loudspeaker,installationguideandpaintshield.
Finish:
Textured black or white finish with a contoured,
powder-coated steel grille. Both the enclosure
and grille can be painted.
Connectors:
Three-terminal barrier strip with a pre-wired
ceramic connector.
Front View Side View
RearView
(cover removed)
Mechanical diagrams:
pro.Bose.com
3
OF 8
TECHNICALDATASHEET

Bose FreeSpace DS 16F Specifications

General

Tweeter	-
Speaker type	Full range
Driver diameter	57 mm
Number of drivers	1
Speaker enclosure	Ported
Speaker placement	Ceiling-mountable
Audio output channels	1.0 channels
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	No
Impedance	8 Ω
Sensitivity	84 dB
Frequency range	80 - 19000 Hz
RMS rated power	16 W
Peak Music Power Output (PMPO)	64 W
Connectivity technology	Wired

Weight and Dimensions

Weight	1900 g
