Bose FreeSpace DS 16F Datasheet

All information subject to change without notice.
©2010 Bose Corporation.
Bose, FreeSpace and Acoustimass are registered trademarks of Bose Corporation
in the United States and other countries.
C_008811
FreeSpace
®
DS 16F
Loudspeaker
Product Codes
FreeSpaceDS16Floudspeaker–Blk PC043053
FreeSpaceDS16Floudspeaker–Wht PC043054
Accessories
Model16tilebridge(6pack) PC029830
Model16rough-inpan(6pack) PC029831
Model16retrofitkit(6pack) PC030096
PC-16plenumcover(6pack) PC031144
Model16pendant-mountkit–Wht PC030095
Model16pendant-mountkit–Blk PC030094
DS16FAdjustableTileBridge PC323204-0010
SquareGrille–Wht PC323207-0210
Replacement Parts
Grille–Blk PN296711
Grille–Wht PN296712
Logo–Wht PN303895
Logo–Blk PN303977
2.25"(57mm)driver(indoor) PN298081
How our Loudspeakers are
Measured
1. Power handling
Full-bandwidthpinknoise,meetingtheIEC
Standard#268-5,isappliedtotheloudspeaker
and amplified to a level at the loudspeaker
terminals corresponding to the power handling of
the loudspeaker. The loudspeaker must show no
visible damage or measurable loss of performance
after 100 hours of continuous testing.
2. Sensitivity
Full-bandwidth pink noise is applied to the loud-
speaker with its active equalization curve and
amplified to a level at the loudspeaker terminals
corresponding to 1 watt, as referenced to the
nominal impedance. The average sound pressure
level(dB-SPL)ismeasuredat1meterfromthe
speaker in an anechoic environment.
3. Maximum SPL
Full-bandwidth pink noise is applied to the loud-
speaker with its active equalization curve and
amplified to a level at the loudspeaker terminals
corresponding to the long-term rated power
handling of the speaker. The average sound
pressurelevel(dB-SPL)ismeasuredat1meter
from the speaker in an anechoic environment.
4. Frequency range
Sine waves are injected into the loudspeaker, and
the level is adjusted to 1 watt, as referenced to
the nominal impedance, and the level measured
at1meter.Resultinggraphissmoothedby0.05
octave-band.
TECHNICALDATASHEET
pro.Bose.com
8
OF 8

Bose FreeSpace DS 16F Specifications

General

Tweeter	-
Speaker type	Full range
Driver diameter	57 mm
Number of drivers	1
Speaker enclosure	Ported
Speaker placement	Ceiling-mountable
Audio output channels	1.0 channels
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	No
Impedance	8 Ω
Sensitivity	84 dB
Frequency range	80 - 19000 Hz
RMS rated power	16 W
Peak Music Power Output (PMPO)	64 W
Connectivity technology	Wired

Weight and Dimensions

Weight	1900 g
