Bose FreeSpace DS 16F Datasheet

FreeSpace
®
DS 16F
Loudspeaker
Recommended Loudspeaker Equalization Curve
Detailed Product Specifications
Additional Product Information
Performance of the FreeSpace
®
DS 16F loudspeaker
can be maximized through the use of the
recommended Bose
®
loudspeaker equalization
resident in select Bose electronics or by using
other equipment with parametric equalization.
The loudspeakers can be used out of the box
with an 80-Hz high-pass filter when recommended
loudspeaker equalization is not used.
1– 4
See “How our Loudspeakers are Measured” on page 8.
Power handling
1
16W
Nominal Impedance (transformer bypass) 8Ω
Sensitivity
2
(at 1W @ 1m) 84 dB-SPL
Maximum SPL
3
96 dB-SPL
(pink noise @ 1m @ rated power) 102 dB-SPL (Peak)
Frequency range
4
(-3 dB) 90 Hz – 16 kHz
Beamwidth (-6 dB point, average 1 – 4 kHz) 140° conical
pro.Bose.com
2
OF 8
TECHNICALDATASHEET

Bose FreeSpace DS 16F Specifications

General

Tweeter	-
Speaker type	Full range
Driver diameter	57 mm
Number of drivers	1
Speaker enclosure	Ported
Speaker placement	Ceiling-mountable
Audio output channels	1.0 channels
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	No
Impedance	8 Ω
Sensitivity	84 dB
Frequency range	80 - 19000 Hz
RMS rated power	16 W
Peak Music Power Output (PMPO)	64 W
Connectivity technology	Wired

Weight and Dimensions

Weight	1900 g
