Bose Panaray MSA12X Service Manual

11
ELECTRICAL PART LIST
SMPS PCB Assembly
Resistors
Reference Designator Description Vendor Vendor Part Number Note
R1, R2, R118, R119 RES, SMD, 1M, 1%, 1/4W, 1206 PANASONIC ERJ-8ENF1004V
R3, R5 RES, SMD, 487K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF4873V
R4, R8, R12, R16 RES, SMD, 120K, 1%, 1/2W, 0805 Panasonic ERJ-P6WF1203V
R6 RES, 0.047 OHM 4W, 1%, AXIAL Ohmite 14AFR047E 3
R7, R27, R34, R46, R47,
R109, R117, R123, R128
RES, 10.0K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1002V
R9, R13, R15 RES, SMD, 2.37M, 1%, 1/8W, 0805 Yageo RC0805FR-072M37L
R10, R22, R26, R33,
R53, R61
RES, 10.0 OHM 1%, 1/10W, 0603 PANASONIC ERJ-3EKF10R0V
R11 RES, 20.0 OHM, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF20R0V
R14 RES, 3.32K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF3321V
R17 RES, SMD, 90.9K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF9092V
R18 RES, 39.2K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF3922V
R19 RES, 11.3K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1132V
R20 RES, SMD, 6.34K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF6341V
R21, R24, R25 RES, SMD, 953K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF9533V
R23, R52, R62 RES, SMD, 4.7, 1%, 1/3W, 0805 PANASONIC ERJ-6BQF4R7V
R28, R81, R127 RES, 4.75K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF4751V
R29, R89 RES, SMD, 1.0, 1%, 1/3W, 0805 PANASONIC ERJ-6BQF1R0V
R30 RES, 2.00K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF2001V
R31, R32 RES, 4.75K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF4751V
R35 RES, 12.1K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1212V
R36, R130 RES, 150K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1503V
R37 RES, 27.4K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF2742V
R38 RES, 15K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1502V
R39 RES, 16.2K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1622V
R40 RES, SMD, 6.19K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF6191V
R41, R42 RES, SMD, 49.9K, 1%, 1/4W, 1206 PANASONIC ERJ-8ENF4992V
R43, R45 RES, SMD, 20K, 1%, 1/4W, 1206 PANASONIC ERJ-8ENF2002V
R44 RES, SMD, 392, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF3920V
R48, R49 RES, 10, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF10R0V
R50, R51, R121, R122 RES, 0.130, 1%, 1/2W, 1206 PANASONIC ERJ-8BSFR13V
R54, R63 RES, 0, JMP, 1/10W, 0603 PANASONIC ERJ-3GEY0R00V
R55, R64 RES, 5.90K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF5901V
R56, R65 RES, 20K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF2002V
R66 RES, SMD, 221 OHM 1%, 1/8W, 0805 PANASONIC ERJ-6ENF2210V
R67, R75 RES, SMD, 10K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF1002V
R68, R115 RES, 1K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF1001V
R69, R78 RES, 2.21K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF2211V
R70, R72 RES, 1K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF1001V
R71, R129 RES, 825 OHM 1%, 1/8W, 0805 PANASONIC ERJ-6ENF8250V
R73, R76 RES, SMD, 42.2K, 1%, 1/4W, 1206 PANASONIC ERJ-8ENF4222V
