Bose Panaray MSA12X Service Manual

12
Resistors (continued)
ELECTRICAL PART LIST
SMPS PCB Assembly
Reference Designator Description Vendor Vendor Part Number Note
R74 RES, SMD, 8.45K, 1%, 1/4W, 1206 PANASONIC ERJ-8ENF8451V
R77 RES, 5.62K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF5621V
R79 RES, 4.42K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF4421V
R80 RES, 825, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF8250V
R82, R108, R111 RES, 100, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1000V
R83 RES, 221K, 1%, 1/4W, 1206 PANASONIC ERJ-8ENF2213V
R84, R91, R99, R104 RES, 60.4, 1%, 1/4W, 1206 PANASONIC ERJ-8ENF60R4V
R85, R93 RES, 13.7K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1372V
R86 RES, 22 OHM 1W, 5%, AXIAL YAGEO FMP100JR-52-22R
R87, R102 RES, 1.27K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF1271V
R88 RES, 1.20K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF1201V
R90 RES, 22, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF10R0V
R92, R95 RES, 4.7K, 5%, 1/4W, 1206 YAGEO RC1206JR-074K7L
R94 RES, 47, 5%, 1/8W, 0805 PANASONIC ERJ-6GEYJ470V
R96 RES, 4.75K, 1%, 1/10W, 0603 Panasonic ERJ-3EKF4751V
R97 RES, SMD, 1 OHM 1%, 1/2W, 1210 PANASONIC ERJ-14BQF1R0U
R98, R135 RES, 0 OHM 1/8W, 0805 PANASONIC ERJ-6GEY0R00V
R100 RES, 3.74K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF3741V
R101 RES, 100 OHM 5%, 1/8W, 0805 PANASONIC ERJ-6GEYJ101V
R103 RES, NTC, 100K, 5%, 1/10W, 0603 MURATA NCP18WF104J03RB
R105 RES, 2.21K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF2211V
R106 RES, 750, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF7500V
R107 RES, THICK FILM, 7.15K, 1%, 1/10W,
0603
PANASONIC ERJ-3EKF7151V
R110, R124, R133, R134 RES, 49.9K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF4992V
R112 RES, SMD, 4.32K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF4321V
R113 RES, 100K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF1003V
R114 RES, 33.2 OHM 1%, 1/16W, 0603 PANASONIC ERJ-3EKF33R2V
R116 RES, 0 OHM, JMP, 1/10W, 0603 PANASONIC ERJ-3GEY0R00V
R120 RES, 10 OHM 1%, 1/2W, 1206 Vishay Dale CRCW12060000Z0EC
R125 RES, 33.2K, 1%, 1/10W, 0603 PANASONIC ERJ-3EKF3322V
R126 RES, 75K, 1%, 1/8W, 0603 PANASONIC ERJ-6ENF7502V
R131 RES, 22.1K, 1%, 1/16W, 0603 PANASONIC ERJ-3EKF2212V
R132 RES, 1.21K, 1%, 1/8W, 0805 PANASONIC ERJ-6ENF1211V
Capacitors
Reference Designator Description Vendor Vendor Part Number Note
C1, C2, C107 CAP, FILM, 0.47uF, 10%, 310VAC, RAD Wurth, Elec-
tronics
8.90334E+11 3
C3 CAP, FILM, 0.33uF, 10%, 630VDC, RA-
DIAL
Kemet R463I33305002K
C4 CAP, FILM, 0.33uF, 5%, 630VDC, RADI-
AL
Panasonic ECW-FA2J334J
