Bose Panaray MSA12X Service Manual

13
Capacitors (continued)
ELECTRICAL PART LIST
SMPS PCB Assembly
Reference Designator Description Vendor Vendor Part Number Note
C5, C116 CAP, CER, 0.47uF, 50V, 5%, X7R, 0805 Kemet C0805C474J5RACTU
C7, C44, C97, C98, C99 CAP, AL ELECT, 120uF, 420V, 20%, Ra-
dial, 22x32MM
Nichicon LQSW6121MELZ30
C8, C23 CAP, CER, 10uF, 25V, X7R, 1206 Samsung CL31B106KAHNNNE
C9 CAP, CER, 1000pF, 50V, 5%, NP0, 0603 Kemet C0603C102J5GACTU
C10, C40, C41, C78 CAP, CER, 1000pF, 50V, 5%, NP0, 0603 Kemet C0603C102J5GACTU
C11, C32, C34, C36,
C43, C50, C52, C53,
C57, C61, C63, C68,
C69, C70, C84, C89,
C113, C114
CAP, CER, 1uF, 25V, 10%, X7R, 0603 Taiyo Yuden TMK107B7105KA-T
C12 CAP, CER, 0.22uF, 50V, 10%, X7R, 0603 Samsung CL10B224KB8VPNC
C13 CAP, CER, 470pF, 50V, 5%, NP0, 0805 Kemet C0805C471J5GACTU
C14, C117 CAP, CER, 2.2uF, 10%, 16V, X7R, 0805 Yageo CC0805KKX7R7BB225
C15 CAP, CER, 0.22uF, 100V, X7R, 0805 Kemet C0805C224K1RACTU
C16, C27 CAP, FILM, 0.018uF, 5%, 1KVDC, RADI-
AL
EPCOS
(TDK)
B32641B0183J
C17, C38, C55, C56,
C65, C73, C74, C92
CAP, CER, 10UF, 25V, 10%, X7R, 1206 Taiyo Yuden TMK316B7106KL-TD
C18, C20, C31, C33,
C37, C54, C62, C71,
C85, C93, C94, C95,
C96, C118
CAP, CER, 0.1uF, 50V, 10%, X7R, 0603 Kemet C0603C104K5RACTU
C19 CAP, CER, 4.7uF, 16V, 10%, X7R, 0805 Samsung CL21B475KOFNNNE
C21 CAP, CER, 220pF, 100V, 5%, C0G, 0805 TDK CGJ4C2C0G2A-
221J060AA
C22 CAP, FILM, 1uF, 5%, 100VDC, RADIAL Kemet R82EC4100Z370J
C24 CAP, CER, 0.1uF, 100V, X7R, 0805 Kemet C0805C104K1RACAU-
TO
C25 CAP, ALUM, 220uF, 20%, 63V, SMD Nichicon UCZ1J221MNQ1MS
C26 CAP, AL ELECT, 560uF, 63V, 20%, Radi-
al, 12.5x27MM
Nichicon UHW1J561MHD1TO
C28, C39 CAP, CER, 0.1uF, 100V, 10%, X7R, 0805 Samsung CL21B104KCFNNNE
C29, C30 CAP, CER, 330pF, 100V, 5%, C0G, 0603 Murata GRM-
1885C2A331JA01D
C35, C47 CAP, CER, 2200pF, 760V, Y5U, RADIAL Kemet C961U222MWWD-
BA7317
3
C42, C87 CAP, CER, 10000pF, 50V, 5%, NP0, 0603 Murata GRM1885C1H-
103JA01D
C45 CAP, FILM, 0.1uF, 10%, 560VDC, RADI-
AL
Kemet R46KI3100DQM1K
C46 CAP, CER, 2200pF, 1KV, 10%, RADIAL TDK CK45-B3AD222KYNNA
C48, C59, C67, C76 CAP, CER, 390pF, 450V, 5%, NPO, 0805 TDK C2012C0G2W-
391J060AA
C49, C51, C58, C60 CAP, ALUM, 470uF, 20%, 25V, SMT,
8.3MM
Nichicon UCM1E471MNL1GS
