Bose SoundLink Mini

7
Item Description Material Number QTY Note
1 GASKET, GRILLE, FRONT, NG5 626978-0020 1
2 ADHESIVE STRIP, DIE CUT, GRILLE 729681-0010 2
3 SCREW, THRDROLL, 2-56X3/8, PAN, TORX 360575-006 8
4 BAFFLE, FRONT 357404-0020 1
3
؍
5 PASSIVE RADIATOR 357793-0010 1
6 TWID ASSY, 39.5OD, REVOLVER, SuFREE SRND 360563-0040 2
3
؍
7 SCREW, THD FRM, 2-28X1/4, PAN 289396-004 4
8 PCB ASSY, SOUNDLINK MINI BT 2, BOOST, SVCE 716536-002S 1
9 KEYPAD, 5 POSITION, NG4 727755-0020 1
KEYPAD, 5 POSITION, BLACK 727755-0010 1
10 CAP, TOP, NG4 757367-0020 1
CAP, TOP, BLACK 757367-0010 1
11 ADHESIVE, DIE CUT, TOP CAP 729581-0010 1
12 GASKET, MAIN PCB 730114-0020 1
13 PCB ASSY, KCUP, AMP, SVCE 716527-002S 1
3 ؍
14 SCREW, THRDROLL, 2-56X3/8, PAN, TORX 360575-006 4
15 ADHESIVE STRIP, DIE CUT, GRILLE 729681-0010 2
16 GASKET, GRILLE, REAR, NG 5 729899-0020 1
3,
؍
17 REAR GRILLE, BLK, SL MINI II, SNGL, SERV 357407-002S 1
REAR GRILLE, NG3, SL MINI II, SNGL, SERV 357407-003S 1
REAR GRILLE, BLK, SL MINI II, BULK, 400 per carton 357407-0020
REAR GRILLE, NG3, SL MINI II, BULK, 400 per carton 357407-0030
18 FILTER, MICROPHONE, 8MM OD (use gloves to handle,
see page 33 for details)
744588-0010 1
19 SCREW, THRDROLL, 2-56X5/8, PAN, TORX 360575-010 4
20 PCB ASSY, SOUNDLINK MINI BT 2, IO, SVCE (does not
include mic fi lter, item 18)
716544-002S 1
21 BAFFLE, REAR 357405-0020 1
3
؍
22 PASSIVE RADIATOR 357793-0010 1
23 SCREW, THD FRM, 2-28X1/4, PAN 289396-004 4
24 SLAB ASSY, SOUNDLINK MINI BT 2, MAIN, SVCE 716517-004S or
755974-002S
1
3
؍
25 GROMMET, FFC, MOLDED 361348-0010 1
26 CABLE, FFC, 0.5mm, 34COND 357413-0010 1
27 ENCLOSURE, EXTRUSION, CARBON 732932-0020 1
3
؍
ENCLOSURE, EXTRUSION, CLEAR 732932-0010 1
28 HARNESS, XDUCER 357412-0010 1
29 BATTERY PACK, LI-ION, 2CELL, 2SIP 724056-0010 1
30 *FOOT, SILICONE, NG7
*FOOT, SILICONE, NG7, APAC
*756361-0010
*756361-0040
1
31 SCREW, THRDROLL, 2-56X1/4, PAN, TORX 360575-004 1
32 FRONT GRILLE, BLK, SL MINI II, SNGL, SERV 730209-001S 1
3
؍
FRONT GRILLE, WHT, SL MINI II, SNGL, SERV 730209-002S 1
FRONT GRILLE, BLK, SL MINI II, BULK, 400 per carton 730209-0010
FRONT GRILLE, NG3, SL MINI II, BULK, 400 per carton 730209-0020
MAIN PART LIST, SOUNDLINK MINI II
(See Figure 2)
