Bose SOUNDLINK REVOLVE Quick Start Guide

(A) Peel off the rubber adhesive foot.
Remove the three fasteners located under
the foot. Carefully separate the base from
the rest of the unit.
(B) Remove the three fasteners securing the
transducer. Separate the transducer from
the rest of the unit.
Note that the lithium-ion cells are in a pack
below the transducer. Avoid damaging the
battery while disassembling the product.
(C) Separate top cap assembly from the rest
of the unit.
(D) Lift the board and remove the one
fastener underneath.
(E) Flip the unit over and remove the three
remaining fasteners attaching the battery
pack to the unit.
Carefully slide the battery pack out of the
unit.
(F) Removed battery pack shown.
Dispose of the battery pack and the
remainder of the product in accordance
with local regulations.
Cylindrical cell
lithium-ion
battery
SoundLink® Revolve speaker
1
2
4
1
2
3
1
2
3
location of
lithium-ion
battery pack
location of
lithium-ion
battery pack
1
2
1
3
lithium-ion
battery pack
location of
lithium-ion
battery pack
top of unit
bottom of unit

Bose SOUNDLINK REVOLVE Specifications

General

Wi-Fi	-
Bluetooth	Yes
Bluetooth range	9 m
USB connector type	Micro-USB B
Connectivity technology	Wired & Wireless
Cables included	USB
Quantity per pack	1 pc(s)
Power source type	Battery
Battery life (max)	12 h
Number of speakers	1
RMS rated power	- W
Product color	Black
Product design	Cylinder
Volume control	Digital
Built-in display	No
Protection features	Water resistant
International Protection (IP) code	IPX4
Recommended usage	Universal

Weight and Dimensions

Width	82 mm
Height	152 mm
Weight	- g
