Note: Mounting hardware must be purchased separately. If the mounting
hardware instructions differ from these instructions, follow the mounting
hardware instructions.
• Wood Mounting: Mount to 1 in. (25.4 mm) or thicker wood. Drill pilot
hole with a ³/
32 in. (2.38 mm) drill. Use (4) #10 x 1½ in. (M5 x 38 mm)
pan-head wood screws.
s Wallboard Mounting: Mount to Ǫ in. (9.5 mm) or thicker wallboard.
Drill pilot hole with a ½ in. (12.7 mm) drill. Use (4) #10 x 2½ in.
(M5 x 63.5 mm) pan head machine screws and (4) #10 (M5) spring anchors.
1 in. (25.4 mm) minimum
Wood
³/8 in. (9.5 mm) minimum
Wallboard
