Bose T1 ToneMatch - Page 14

14
Electrical Part List
Input/Output PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C239 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C240 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C241 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C242 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C243 0.1uF, CC, 0603/1608, 50V, 10%, 1x2 150F-104K+P-AC 4
C244 100pF, CC, 0603/1608, 50V, 5%, 1X2 150F-101J+P-AC 4
C336 22uF, CE, 16V, 20%, SMD, 5X5.8 157D-226M+3-IKC 4
C337 22uF, CE, 16V, 20%, SMD, 5X5.8 157D-226M+3-IKC 4
Reference
Designator
Description Vendor Part
Number
Note
D13 BAV99, SOT23, PHILIPS 4840-8970+3 4
D14 BAV99, SOT23, PHILIPS 4840-8970+3 4
Diodes
Integrated Circuits
Reference
Designator
Description Vendor Part
Number
Note
U7 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U8 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U13 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U15 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U17 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
U18 NJM2068M-#ZZZB, DUAL OP AMP 3130-6890+0 4
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
CN504B HOUSING, 2X8P, P2.54, STRAIGHT, F 2101-3160+0 4
J1 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J6 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J7 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J8 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J10 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
J11 JACK, SOCKET, NRJ6HF, STEREO 2113-3085+0 4
