Bose T1 ToneMatch Service Manual

9
Main Part List
T1 ToneMatch
®
Audio Engine (see Figure 2)
Item
Number
Description Bose
®
Part
Number
V
endor Part
Number
Qty. Note
1 PANEL, REAR, I/
O
298733 1406-3101+0 1
2 HOUSING, TOP 298730 1468-0401+1 1
3 HOUSING, BOTTOM 298731 1468-0501+1 1
- LID ASSY, CONSISTS OF ITEMS
4, 14, 24, 25, 26 AND 28 BELOW
305293 SVC-SIEN11+LID 1
4 LID, PC+TPE 298746 1468-0701+1 1
5 LCD PCB ASSY 305296 SVC-SIEN11+LCDB 1
6 BOSE LOGO, ALUM 298742 2150-7221+0 1
7 KNOB, CHANNEL VOLUME 298737 2447-4401+1 4
8 KNOB, ROTARY 298739 2447-4501+1 3
9 BUTTON, PHANTOM PWR 298743 2447-4601+1 1
10 KNOB, TRIM 298741 2447-4801+1 4
11 KNOB, MASTER VOLUME 298738 2447-4901+1 2
12 SPRING, 4x10x0.35 - 2510-3971+0 2 4
13 WASHER, SPRING, M3x0.9x5.5 - 2607-3009+0553 6 4
14 WASHER, SPRING, M9x1x11, BZ 307727 2607-9010+1103 1
15 SCREW, MACH, PAN, M3x10 - 2900-3010+3000 6 4
16 SCREW, FLAT-CS, M3x5, B - 2901-3005+3000 2 4
17 SCREW, MACH, FLAT-CS - 2901-3006+3000 1 4
18 SCREW, M3x8, S29503008-3000 - 2920-3008+3000 8 4
19 B-TITE, 3x10, BLK, ZN - 2954-3010+3000 2 4
20 CONNECTOR PCB ASSEMBLY 305297 SVC-SIEN11+I/O 1
21 MOUNTING BKT, REA
R
298749 4135-7071+0 1
22 BRACKET, LCD - 4135-7081+0 1 4
23 NUT, PLASTIC, M10x4.8 - 4155-1031+0 6 4
24 RETAINER, BSPASIEN+05CS11 301567 4155-2631+0 1
25 LATCH, LID 298748 4155-2641+1 1
26 LID RELEASE 298747 4155-2651+0 1
27 PANEL, TOP, FX, PMM
A
298732 4155-2661+1 1
28 MOUNT, SWING ARM 301568 4155-2671+0 1
29 CARRIAGE, 50x100 298750 4155-2721+0 1
30 SCREW, RETENTION, 30x12 298751 4155-2731+0 1
31 SPACER, NYLON, 5x10 - 4155-2791+0 4 4
32 KEYPAD 1, FX MUTE, SILICON 298744 4157-1251+0 1
33 KEYPAD 2, FX MUTE, SILICON 298745 4157-1261+0 1
34 RUBBER FOOT, 9x18x2 331349-
001S
4157-1271+0 4 4
35 SWITCH, ROCKER, 2PIT - 5200-4910+0 1 4
36 CONN WIRE, 2P, P2.0, #28 - 7012-6919+0 1 4
37 WIRE-CONN, 4P, P2.5, #24 - 7012-9180+0 1 4
38 MODULE, LCD, HDG12864L-7 299212 8902-0020+0 1
39 MAIN PCB ASSEMBLY 298756 SVC-SIEN11+MAIN 1

Bose T1 ToneMatch Specifications

General

Sample rate	48 kHz
Channels quantity	- channels
Digital sound processing	- bit
DJ mixer	-
Backlight	Yes
Backlight color	Blue
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	208.9 mm
Width	165.5 mm
Height	67.6 mm
Weight	970 g
