Specifications
AC-3: Acoustic Simulator
Nominal Input Level..................... -20 dBu
Input Impedance............................ 1 MΩ
Nominal Output Level.................. -20 dBu
Output Impedance ........................ 1 kΩ
Recommended Load Impedance ...... 10 kΩ or greater
Controls........................................... Pedal switch, LEVEL knob, REVERB knob, BODY knob,
TOP knob, MODE knob
Indicators ........................................ CHECK indicator (Serves also as battery check indicator)
Connectors...................................... INPUT jack, LINE OUT jack, G.AMP OUT jack,
AC adaptor jack (DC 9 V)
Power Supply................................. DC 9 V: Dry battery/9 V type (6F22 (carbon), 6LR61 (alkaline)) ,
AC Adaptor (PSA-series: optional)
