OCT. 2000 AW-3
3
PARTS LIST/
//
/ パーツリスト
パーツリストパーツリスト
パーツリスト
CASING
/ケース
/ケース/ケース
/ケース
Q'ty
2235730500 BOTTOM BASE 235-305 1
2202785100 BOTTOM COVER 202-851 1
# G2017140 CASE 1
2235730400 FOOT BASE (PEDAL MAT) 235-304 1
# G2217127 PANEL 1
# G2187523 PEDAL 1
KNOB, BUTTON
/つまみ、ボタン
/つまみ、ボタン/つまみ、ボタン
/つまみ、ボタン
22480260 P R-KNOB MF BLK/LCG 4
SWITCH
/スイッチ
/スイッチ/スイッチ
/スイッチ
13129710 JM-0404 SWITCH (PUSH) SW1 on SW BOARD 1
JACK, SOCKET
/ジャック､ソケット
/ジャック､ソケット/ジャック､ソケット
/ジャック､ソケット
13449717 HEC2392-01-150 ADAPTOR JACK JK1 on Main Board 1
13449150MF HTJ-064-12D JACK (STEREO) JK4 on Jack Board 1
13449140MF HTJ-064-14D JACK (STEREO) JK2,JK3 2
# F3449617 SCJ-0641-Z-V-I-C JACK (STEREO) JK1 1
PWB ASSY
/基板完成品
/基板完成品/基板完成品
/基板完成品
# 75D363I000 IN JACK ASSY 1
# 75D363P000 MAIN BOARD ASSY 1
# 75D363O000 OUT JACK ASSY 1
IC
# 02341501 MN101C427BW AW-3 V1.00 IC (8BIT CPU) IC6 on Main Board 1
00452301 NJM2100M IC (OP AMP) IC1 on Main Board 1
# 02560867 S-80930ALMP-DAT-T2 IC (RESET) IC5,IC8 on Main Board 2
01906156 S-8520E33MC-BJS-T2 IC (DC-DC REGULATOR) IC7 on Main Board 1
01235190 TC203C040AF-001(FP) IC (MR2 CHIP) IC4 on Main Board 1
01569567 UDA1340M IC (AD/DA FLAT) IC3 on Main Board 1
15289105 UPC4570G2-E2 IC (BIPOLAR OP AMP) IC2 on Main Board 1
SAFETY PRECAUTIONS:
The parts marked have safety-related characteristics. Use only listed parts for replacement.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completery fill the above items with correct number and description will result in delayed or
even undelivered replacement.
) 10 22575241 Sharp key C-20/50
15 2247017300 Knob (orange) DAC-15D
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
SAFETY PRECAUTIONS:
NOTE:The parts marked # are new (initial parts)
#
DSB ---> DSP BOARD MSB ---> PB -->
JB ---> JACK BOARD IJB --->
MEMORY SWITCH BOARD
INPUT JACK BOARD PS1B -->
POWER BOARD
PS1 BOARD
TRANSISTOR
/ トランジスター
/ トランジスター/ トランジスター
/ トランジスター
15309104 2SA1586-GR(TE85R) TRANSISTOR Q9,Q10 on Main Board 2
15319107 2SC4116-GR(TE85R) TRANSISTOR Q6,Q8 on Main Board 2
F5329502 2SJ190 TRANSISTOR Q7 on Main Board 1
15329103T0 2SK880-GR(TE85R) FET TRANSISTOR Q1,Q2,Q3 on Main Board 3
15329521 RN1307(TE85R) TRANSISTOR Q4,Q5 on Main Board 2
DIODE
/ダイオード
/ダイオード/ダイオード
/ダイオード
15339119T0 1SS352(TPH3) SWITCHING DIODE D1,D2 on Main Board 2
# F5029123 L-115VEGW LED LED1 on VR Board 1
F5339137 SS14 VF=0.45V DIODE D3,D4,D5 on Main Board 3
RESISTOR
/抵抗
/抵抗/抵抗
/抵抗
F5399906 10KF MTL.FILM RESISTOR R26 on Main Board 1
F5399907 150KF MTL.FILM RESISTOR R24 on Main Board 1
00567156 RPC05T 102 J MTL.FILM RESISTOR R10,R28,R45 on Main Board 3
00567289 RPC05T 103 J MTL.FILM RESISTOR R7,R15,R22,R25,R30,R31,R32,R36,R37,
R38,R40,R46 on Main Board
12
00567412 RPC05T 104 J MTL.FILM RESISTOR R14,R43,R44 on Main Board 3
00567556 RPC05T 105 J MTL.FILM RESISTOR R1,R9,R16,R17,R19,R23 on Main Board 8
00567067 RPC05T 221 J MTL.FILM RESISTOR R34,R35 on Main Board 2
00567190 RPC05T 222 J MTL.FILM RESISTOR R39 on Main Board 1
00567323 RPC05T 223 J MTL.FILM RESISTOR R4,R5,R6,R21,R47,R48 on Main Board 6
00567456 RPC05T 224 J MTL.FILM RESISTOR R27 on Main Board 1
00567089 RPC05T 331 J MTL.FILM RESISTOR R2,R12 on Main Board 2
00567345 RPC05T 333 J MTL.FILM RESISTOR R50 on Main Board 1
00567367 RPC05T 393 J MTL.FILM RESISTOR R3,R13,R42 on Main Board 3
00567389 RPC05T 563 J MTL.FILM RESISTOR R8,R11,R20,R49 on Main Board 4
00567523 RPC05T 684 J MTL.FILM RESISTOR R18,R29 on Main Board 2
POTENTIOMETER
/ボリューム
/ボリューム/ボリューム
/ボリューム
# F3279793 RD901-40-15FW-B54-00D POTENTIOMETER VR2,VR3,VR4 on VR Board 3
# F3279794 RD901-40-15FW-B54-05D
5CLICK
POTENTIOMETER VR1 on VR Board 1
CAPACITOR
/コンデンサー
/コンデンサー/コンデンサー
/コンデンサー
F5359317 0603 5P 50VJ CERAMIC CAPACITOR C40,C42,C64 on Main Board 3
F5367542 10/16V ALUMINIUM ELECTROLYTIC CAPACITOR C2,C9,C10,C13,C14,C18,C19 on Main Board 7
F5367546 100/16V ALUMINIUM ELECTROLYTIC CAPACITOR C34,C36,C43,C51 on Main Board 4
# F5369547 47/16V ALUMINIUM ELECTROLYTIC CAPACITOR C37 on Main Board 1
F5367503 47/6.3V ALUMINIUM ELECTROLYTIC CAPACITOR C24,C26,C29,C38 on Main Board 4
01906178 ECPU1C104MA5 (SUBMICRON) MYLAR CAPACITOR C7 on Main Board 1
02341489 ECPU1C474MA5 (SUBMICRON) MYLAR CAPACITOR C1,C11,C12 on Main Board 3
00567967 GRM39B153K50PT CERAMIC CAPACITOR C4,C15 on Main Board 2
00567867 GRM39B222K50PT CERAMIC CAPACITOR C3,C6,C16,C58 on Main Board 4
01675278 GRM39CH101J50PT CERAMIC CAPACITOR C5,C8,C41,C63 on Main Board 4
00567978 GRM39F104Z25PT CERAMIC CAPACITOR C17,C21-C23,C25,C27,C28,C31,C32,
C35,C44-C50,C52-C55,C57,C59-C62
on Main Board
26
INDUCTOR, COIL, FILTER
/インダクター、コイル、フィルター
/インダクター、コイル、フィルター/インダクター、コイル、フィルター
/インダクター、コイル、フィルター
F2449209 SLF7032T-151MR29-2(150UH) COIL L2 on Main Board 1
F2449210 SLF7032T-4R7M1R7-2(4.7UH) COIL L1 on Main Board 1
CRYSTAL, RESONATOR
/クリスタル、発振子
/クリスタル、発振子/クリスタル、発振子
/クリスタル、発振子
# 02560445 CX-16F 33.8688MHZ CRYSTAL X1 on Main Board 1
