Boss EQ-200 - STRUCT (STRUCTURE) = PARA (PARALLEL), LINK = OFF; STRUCT (STRUCTURE) = SERIES

Overall Settings (Menu)
11
STRUCT (STRUCTURE)= PARA (PARARELL), LINK = OFF
Operates as two independent mono EQs.
INPUT B
EQ A
EQ B
INPUT A
OUTPUT A
OUTPUT B
Not linked
Post EQ
Pre EQ
Guitar
Distortion-type
external eect
STRUCT (STRUCTURE) = SERIES
If you set the unit's footswitch settings to A and B, it
operates as two mono EQ units connected in series.
INPUT A
INPUT B
EQ A
OUTPUT A
EQ B
OUTPUT B
