Device and Product Description
Clinician Manual
90607862-30 3 of 309
Precision™ IPG’s 8 contact ports or 8 contact
OR Cables.
Percutaneous Trial Leads
Trial Lead Kit, containing the Linear™ Lead
and the associated components, is intended
to be used for the temporary trial phase.
Lead Extension
Lead Extensions are designed to connect
the percutaneous and paddle leads to the
Precision IPG for spinal cord stimulation.
The extension may be added to a lead to
externalize the lead for a trial procedure or
to extend the lead when a permanent IPG is
implanted.
Lead extensions are available in lengths of
25 cm, 35 cm, and 55 cm. Each extension
has eight electrode contacts located near
the distal end. Each contact is 3 mm in
length and is spaced 1 mm from the adjacent
contact. The extension can be connected to
either the Trial Stimulator (via an OR Cable
Assembly included in the Leads Kit) or
directly to the Precision IPG.
Lead Splitter
The 2x4 Splitters are designed to connect
multiple percutaneous leads to the Precision
IPG. The Linear leads may be inserted
into a splitter for a maximum of four Linear
leads per IPG. Four of the eight contacts
of each Linear lead will be activated. Two
congurations of 2x4 splitters are available:
Distal 4 (D4) and Wide 4 (W4). The two
versions offer different contact congurations.
The Lead Splitter 2x8 is required to connect
the Innion™ 16 contact lead to the IPG. Only
one Innion™ 16 lead through one Splitter
2x8 can be connected to a Precision IPG.
