The BougeRV fridge/freezer is equipped with a battery preservation monitor.It
hasthree settings to monitor your battery to prevent a full discharge. The higher
the setting the higher the cut-off voltage will be.
When set to HIGH, the battery monitor will provide maximum protection for the
battery running the fridge/freezer against excessive/full discharge.
When set to LoW, the battery monitor will allow the fridge/freezer to use more of
the battery energy.
Recommended temperature for common food:
The battery monitor will shut off the fridge/freezer as soon as the supply voltage-
falls below the set level. The fridge/freezer will restart after 2 minutes once the
cut-in voltage is reached.
6.Car Battery Protection Voitage Reference
Voltage
NOTE:
Factory default voltage protection level sets to H Mode
Cut-out is the input voltage in which the fridge/freezer will turn off at.
Cut-in is the input voltage in which the fridge/freezer will turn on at.
High mode
12V DC
Cut out11.3V10.1V9.6V
12.5V11.4V10.9V
24.6V22.3V21.3V
26.0V23.7V22.7V
Cut in
Cut out
Cut in
24V DC
Medium ModeLow mode
To Next Page
