74
M21-M26-M30
11. Maintenance 11.
11.5.6 Economy Filter Maintenance
Observe safety regulations concerning the handling of solvent (see Point 2).
You must perform the maintenance on the economy filter when an adjustable number of cycles has run
or at least once a week.
The filter pressure is displayed on the filter pressure gauge (8)*. When the machine has run through the
specified number of cycles, a diagnostic message (see diagnosis list) indicates that it is time for filter
maintenance.
On machines with an additional cartridge filter (7), you must separate it from the economy filter (6) when
you perform maintenance on the economy filter. Do this by opening the ball valve (1) and closing ball
valves (2) and (3).
Start filter maintenance program P46 (filter 1) or P47 (filter 2):
+ + or + +
707760-05-0
* For filter 1, the pressure gauge is on the front of the machine.
