P12 /P15 /P18
6. Operation 6.
6.1.4. Filling Slimsorba Carbon Container (Optional Equipment)
- Loosen the upper tube of the carbon container (disassemble hose connections, and aeration
line).
- Loosen the quick release fastener on the cover and lift off the cover.
- Remove fine filter sieve and clamping ring.
- Fill in 13 kg/28.7 lb of activated carbon (cylindrical pellets with approx. 4 mm/0.16 inch diameter,
type SUPERSORBON K40). The heating coil must be covered.
- Replace the fine filter sieve and clamping ring.
- Replace the cover and close the quick release fastener.
- Secure the upper tube of the carbon container again (assemble hose connections, and aeration
line).
6.1.5. Filling the Water Separator
 Pump solvent from tank I to the still for about 15 seconds:
+ + + 15 seconds
+ + +
The distillation heating starts automatically. Distillation fills the water separator.
6.1.6. Filling the Economy Filter
 Start filter maintenance program P46 (filter 1) or P47 (filter 2), starting with step n09
+ + + + „fill drum“ +
When using filter powder (optionally):
- First place the precoating bag with the prescribed amount of filter powder (1.2 kg/2.6 lb) into
the cage, then start P46 (filter 1) or P47 (filter 2), as described above..
Attention:
Do not use filter powder on machines with an emission-free still
rakeout system.
PROG
5
9
START
STOP
C
C
PROG
HOLD
PROG
4
6
HOLD
START
