55
P12 /P15 /P18
7. Functional Units 7.
Loading Door Venting
After you open the loading door, the so-called loading door venting starts. The Slimsorba fan helps to
draw fresh air in over the loading door; the air is guided over the carbon and then either blown back
out into the open * or fed back into the cage. Loading door venting should prevent the operator from
being exposed to solvent fumes when loading and unloading the machine.
Loading door venting runs until you close the loading door. When you open the loading door
again, loading door venting starts again.
* (only in certain countries)
707769-13-0
If any overpressure arises in the machine, it is also fed over the carbon into the open, just like the air
drawn in during loading door venting when the cage is being loaded and unloaded.
