15 - Gemini R and Pro | Specifications
gemini r and pro accessories
14 - Gemini R and Pro | Accessories & Specifications
Model:
GM500PRO GM750PRO GM1000PRO GM1500PRO
Part Code BW-3925 BW-3935 BW-3945 BW-3955
Max Power 500Ws 750Ws 1000Ws 1500Ws
Power Range 5 stops (full to 1⁄32) 5 stops (full to 1⁄32) 7 stops (full to 1⁄128) 7 stops (full to 1⁄128)
Power Control Twin Rotary Dial (1-stop or 1/10-stop control) Twin Rotary Dial (1-stop or 1/10-stop control) Twin Rotary Dial (1-stop or 1/10-stop control) Twin Rotary Dial (1-stop or 1/10-stop control)
Modelling Control full / proportional / user defined / off full / proportional / user defined / off full / proportional / user defined / off full / proportional / user defined / off
Ready Indication Illuminated Test Button Illuminated Test Button Illuminated Test Button Illuminated Test Button
Fan Cooled
Yes Yes Yes Yes
Auto Dump (resistive & flash) Yes Yes Yes Yes
Modelling Lamp 250W Halostar (230V BW-1024/A)
250W Halostar (230V BW-1024/B)
250W Halostar (230V BW-1024/A)
250W Halostar (230V BW-1024/B)
E11 230V 500W (BW2515) / 230V 300W (BW2510)
E11 117V 500W (BW2530) / 230V 250W (BW2525)
E11 117V 100W (BW2520)
E11 230V 500W (BW2515) / 230V 300W (BW2510)
E11 117V 500W (BW2530) / 230V 250W (BW2525)
E11 117V 100W (BW2520)
Flash Tube
Three-pin Clear FT - BW-2980
Three-pin UV coated FT - BW-1079
Three-pin Clear FT - BW-2980
Three-pin UV coated FT - BW-1079
Three-pin Clear FT - BW-2980
Three-pin UV coated FT - BW-1079
Three-pin Clear FT - BW-2980
Three-pin UV coated FT - BW-1079
Glass Dome Protective Cover No No Yes Yes
Guide No. (m/100 ISO) 85 104 120 150
Recycle to Full Power 1.1 secs 1.5 secs 2.0 secs 2.8 secs
Flash Duration (at full power) 1/2900 sec. 1/2300 sec. 1/2100 sec. 1/14 00 sec.
Colour Temperature 5600K ±300K 5600K ±300K 5600K ±300K 5600K ±300K
Plug-in Trigger
Module Compatible
Yes Yes Yes Yes
Sync Voltage 5V DC 5V DC 5V DC 5V DC
Operating Voltage
Multivoltage (90-130V AC 60 Hz & 195-250V AC 50Hz) Multivoltage (90-130V AC 60 Hz & 195-250V AC 50Hz) Multivoltage (90-130V AC 60 Hz & 195-250V AC 50Hz) Multivoltage (90-130V AC 60 Hz & 195-250V AC 50Hz)
Travelpak Compatibility Yes Yes Yes Yes
Voltage Stabilisation +/- 0.5% +/- 0.5% +/- 0.5% +/- 0.5%
Ready Light Indication Yes Yes Yes Yes
Flash Inhibit Yes Yes Yes Yes
Audible Ready Sound Yes Yes Yes Yes
Width 170mm (6
3
⁄4”) 170mm (6
3
⁄4”) 170mm (6
3
⁄4”) 170mm (6
3
⁄4”)
Length 410mm (16
1
⁄4”) 410mm (16
1
⁄4”) 459mm (18
1
⁄8”) 519mm (20
3
⁄8”)
Height 133mm (5
1
⁄4”) 133mm (5
1
⁄4”) 133mm (5
1
⁄4”) 133mm (5
1
⁄4”)
Weight 3.5kg (7.7lbs) 4.0kg (8.8lbs) 4.5kg (9.9lbs) 5.0kg (11lbs)
Model:
GM250R GM500R
Part Code
230V - BW-3900
117V - BW-3905
230V - BW-3910
117V - BW-3915
Max Power 250Ws 500Ws
Power Range 5 stops (full to 1⁄32) 5 stops (full to 1⁄32)
Power Control Twin Rotary Dial (Stops or Tenths) Twin Rotary Dial (Stops or Tenths)
Modelling Control
full / proportional /
user defined / off
full / proportional /
user defined / off
Ready Indication
Illuminated Test Button Illuminated Test Button
Fan Cooled
No No
Auto Dump (resistive & flash) Yes Yes
Modelling Lamp
250W Halostar (230V - BW-1024/A)
250W Halostar (117V - BW-1024/B)
250W Halostar (230V - BW-1024/A)
250W Halostar (117V - BW-1024/B)
Flash Tube
Two-Pin Clear FT - BW-2030
Two-Pin UV coated FT - BW-2032
Two-Pin Clear FT - BW-2030
Two-Pin UV coated FT - BW-2032
Glass Dome Protective Cover No No
Guide No. (m/100 ISO) 60 85
Recycle to Full Power 1.0 sec 1.3 secs
Flash Duration (at full power) 1/1100 sec. 1/900 sec.
Colour Temperature 5600K ±300K 5600K ±300K
Plug-in Trigger
Module Compatible
Yes Yes
Sync Voltage 5V DC 5V DC
Operating Voltage 230V AC 50Hz or 117V AC 60Hz 230V AC 50Hz or 117-V AC 60Hz
Travelpak Compatibility Yes Yes
Voltage Stabilisation
±0.5% ±0.5%
Ready Light Indication Yes Yes
Flash Inhibit Yes Yes
Audible Ready Sound Yes Yes
Width
170mm (6
3
⁄4”) 170mm (6
3
⁄4”)
Length
380mm (14
7
⁄8”) 380mm (14
7
⁄8”)
Height
133mm (5
1
⁄4”) 133mm (5
1
⁄4”)
Weight
2.9kg (6.4lbs) 3.4kg (7.5lbs)
This is a good general-purpose direct
reflector with an even coverage and a high
light output. Since it has a small 20cm (8”)
diameter, the light it produces is moderately
high in contrast.
BW1887 - 65º Maxilite Reflector
This four-leaf barn-door attachment allows a
greater degree of control over the light
spread. This attachment also incorporates a
gel holder allowing the use of the BW2364 Gel
Set for creative lighting.
BW2363 - Barn-Door & Gel Holder
Barn-Door &
Gel holder for
Maxilite
65º Maxilite
Reflector
These grids fit on to the front of the Maxilite
Reflector and deliver a very tight controlled
pool of illumination, creating a highly efficient
spot effect.
BW1891 -
3
⁄8” (9.525mm) Wide Angle Grid
BW1892 -
1
⁄4” (6.35mm) Narrow Angle Grid
The pocket-sized Gemini remote control
makes working with compatible Gemini
monolights a breeze. Weighing just 34g, this
diminiutive device allows precise control of
many of the main features.
BW3960 - Gemini IR Remote Control
Gemini IR
Remote Control
Honeycomb
Grids for
Maxilite
R specifications Pro specifications
