Hardware List
Check Quantity Description Reference #
22 Allen Screw M8 x P1.25 x 15 a
6 Phillips Head Screw M8 x P1.0 x 15 b
6 Allen Screw M8 x P1.25 x 15 c
6 Phillips Head Screw 4 x 16 d
1 Allen Wrench 5mm/Screwdriver e
1 Allen Wrench 6mm f
1 Safety Key/Clip g
1 Silicon Lube h
1 *Power Cord (attached on 3.1 model) i
Note: Please verify you have all correct parts and quantities before assembling the unit.
If you are missing items, are short quantities, or have damaged components, please contact Nautilus, Inc.
at 1-800-864-1270 (USA), 1-800-636-8316 (French Canadian) or +41-26-460-77-77 (International).
