Bowflex MAX Trainer M9 - Specifications; Before Assembly; Before Assembly; Basic Assembly Tips; Machine Mat

Assembly / Owner’s Manual
6
Before Assembly
Select the area where you are going to set up and operate your machine. For safe operation, the location must be on a hard, level surface. Allow a
workoutareaofaminimum139cm(54.8”)x186cm(73.2”).Keeptheworkoutareaclear0.6m(24”)alongthesideusedtoaccessthemachineand
to the rear of the machine. Be sure that the workout space you are utilizing has adequate height clearance, taking into consideration the height of
theuserandthemaximumpedalheightofthetnessmachine.
Basic Assembly Tips
Follow these basic points when you assemble your machine:
• Readandunderstandthe“ImportantSafetyInstructions”before
assembly.
• Collect all the pieces necessary for each assembly step.
• Using the recommended wrenches, turn the bolts and nuts to
the right (clockwise) to tighten, and the left (counterclockwise) to
loosen, unless instructed otherwise.
• When attaching 2 pieces, lightly lift and look through the bolt
holes to help insert the bolt through the holes.
• The assembly requires 2 people.
Machine Mat
TheBowex™MaxTrainer™MachineMatisanoptionalaccessorythathelpskeepyourworkoutareaclearandaddsalayerofprotectiontoyour
oor.Therubbermachinematprovidesanon-slip,rubbersurfacewhichlimitsstaticdischargeandreducesthepossibilityofdisplayerrors.Ifpos-
sible,putyourBowex™MaxTrainer™MachineMatinyourselectedworkoutareabeforeyoubeginassembly.
To order the optional machine mat, contact Customer Service (if purchased in US/Canada) or your local distributor (if purchased outside US/
Canada).
Specifications / Before Assembly
Maximum User Weight:  136kg(300lbs.)
Total Surface Area (footprint) of equipment: 9775 cm
2
(1515.4 in
2
)
Maximum Pedal Height: 48.5 cm ( 19.1 inches )
Machine Weight: approx.67.5kg(148.8lbs.)
Power Requirements:
(AC Adaptor)
 InputVoltage:  100-240VAC,50-60Hz,1.5A
Output Voltage: 12V DC, 5A
Heart Rate Armband: 1 Lithium Polymer battery (not replaceable)
DO NOT dispose of this product as refuse. This product is to be recycled. For
proper disposal of this product, please follow the prescribed methods at an
approved waste center.
165.4cm
(65.1”)
125cm
(49.2”)
78.2cm
(30.8”)
1.86m (73.2”)
1.39m
(54.8
”)
0.6m
( 24” )
0.6m
( 24” )
