Assembly / Owner’s Manual
8
Tools
Included
#2
4 mm
5 mm
6 mm
8 mm
13 mm
Hardware / Tools
Item Qty Description Item Qty Description
A 6 Socket Head Hex Screw, M8x1.25x20 Black I2Wave Washer, 17.2x22
B 6 Lock Washer, M8x14.8 Black J4Socket Head Hex Screw, M8x1.25x55 Black
C 12 Washer, Flat M8x18 Black K 4 Lock Nut, M8 Black
D4Socket Head Hex Screw, M10x1.5x25 Black L 8Flat Socket Head Hex Screw, M6x1.0x30 Black
E4Washer, Flat M10x23 Black M4Socket Head Hex Screw, M6x1.0x14 CL10.9 Black
F1Pan Phillips Screw, M5x0.8x20 Black N 10 Lock Washer, M6x14.8 Black
G2Washer, Flat M8x24 Black O4Washer, Flat M6x13 Black
H 2 Cap P 6 Socket Head Hex Screw, M6x1.0x20 CL12.9 Black
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may be remaining Hardware
after the proper assembly of your machine.
AB C D E F
GH
IJK L MN OP
