BOWMAN EC Series - 1 Safety; Hazards When Handling the Oil Cooler; Safety Instructions; Approved Use

2
3
4. Commissioning 8
5. Maintenance / Repair
5.1 Winter shut-down in
areas exposed to frost 8
5.2 General Maintenance 9
5.3 Cleaning 9
5.4 End cover bolt
tightening sequence 9
6. Potential Service Issues 10
6.1 Tube failures 10
6.2 Fault nding 10
7. Warranty 11
8. Spare Parts 11
9. CE Marking Documentation11
10. Notes on zinc anodes 11
BOWMAN® Hydraulic Oil Coolers are constructed to current practice and recognised safety
standards. Hazards may still arise from operation, such as:
• Injury of the operator or
• Third parties or
• Damage to the oil cooler or
• Damage to property and equipment
Any person involved with the installation, commissioning, operation, maintenance or
repair of the cooler must be:
• Physically and mentally capable of performing such work
• Appropriately qualied
• Comply completely with the installation instructions
The oil cooler must only be used for its intended purpose.
In the event of breakdowns which may compromise safety, a qualied person must always be contacted.
1.2 Safety Instructions
The following symbols are used in these operating instructions:
This symbol indicates an immediate danger to health.
Failure to comply with this instruction may result in severe injury.
This symbol indicates a possible danger to health.
Failure to comply with this instruction may result in severe injury.
This symbol indicates a possible risk to health.
Failure to comply with this instruction may result in injury or damage to property.
This symbol indicates important information about correct handling of the equipment
Failure to comply with this instruction may cause damage to the heat exchanger
and/or its surroundings.
1.3 Approved use
1. Safety
1.1 Hazards When Handling the oil cooler
BOWMAN® Hydraulic Oil Coolers are only approved for cooling hydraulic oil.
Any other use unless sanctioned by BOWMAN® is not approved.
BOWMAN® declines all liability for damage associated or arising from such use:
The maximum permissible operating pressure must not exceed:
Oil side: 20 bar max.
Water side: 16 bar max.
Applies to EC-RK three pass threaded connections only – for other versions
please contact BOWMAN® for guidance.
Danger
Caution
Take Care
