BOXER 600HD - Left Rear View

Operating Controls
2.2
Left Rear View
Item No. Description
1 Attachment mounting plate
2 Operating controls
3 Left track assembly
4 Operator’s Platform
5 Lift point
6 Radiator
7 Fuel Tank
8 Fuel ller cap/fuel gauge
9 Loader arms
10 Attachment hydraulic quick connects
3
7
4
8
6
2
5
10
1
9
