BOXER 600HD - Weekly Maintenance Procedures

Routine Service and Maintenance
4.16
Weekly Maintenance Procedures
Do the following procedures weekly or every 50 operating hours:
1. Do all Daily maintenance procedures.
2. Check the battery (Item 4, Figure 4–17) and cable connections (Items 5 and 6,
Figure 4–17) for signs of leaking, corrosion or damage.
Make sure that the battery clamp (Item 3, Figure 4–17) is securely holding the battery in
position. If needed, tighten the lock nut (Item 1, Figure 4–17) to secure the battery.
If the lock nut has fallen o, make sure to replace the lock nut (Item 1, Figure 4–17)
and the lock washer (Item 2, Figure 4–17).
Figure 4-17 Battery and Cable Connections
5
4
1
2
3
6
NOTICE
