Serial No.s 5121 and Higher
Part No. 76347-314
Manufactured by:
700HDX Operator’s Manual
Phone: Morbark
®
, LLC.
Sales - 800-831-0042 8507 S. Winn. Rd., P.O. Box 1000,
Parts and Service - 800-255-8839 Winn, Michigan 48896
www.boxerequipment.com www.morbark.com
BIG POWER IN ALL PLACES
®

Table of Contents

Questions and Answers

  • X
    xhenryAug 4, 2025
    Why is my BOXER Compact Loader engine losing power?
    • E
      Emma HowardAug 4, 2025
      If your BOXER Compact Loader engine is losing power, try these steps: * Reduce the load on the engine by decreasing ground speed or attachment speed. * Inspect the air cleaner. If it's dirty, clean the air filter housing and replace the filter elements. * Check the engine oil level in the crankcase and add the appropriate engine oil if it is low. Refer to the engine manual for oil specifications. * Ensure that cooling fins and air passages under the engine blower housing are free from obstructions.
  • G
    Gregory MahoneyAug 8, 2025
    What to do if my BOXER Compact Loader engine overheats?
    • J
      Joel MartinezAug 8, 2025
      If your BOXER Compact Loader engine is overheating, here’s what you can do: * Reduce the engine load by reducing ground speed or the speed of any attachments. * Check the engine oil level in the crankcase and add the appropriate engine oil if it is low. Refer to the engine manual for oil specifications. * Make sure the cooling fins and air passages under the engine blower housing are free of obstructions. * Check the coolant level and refill with the type of coolant indicated in the engine manual. * Clean the radiator.
  • R
    Robert MedinaAug 13, 2025
    Why does my BOXER Compact Loader not travel in either forward or reverse?
    • H
      Hunter BarrettAug 13, 2025
      If your BOXER Compact Loader is not traveling in either forward or reverse, here are some things to check: * Ensure the engine is running at full speed by advancing the throttle. * If the hydraulic fluid is cold, fully warm it up. * Check the hydraulic fluid level and fill the tank with the appropriate hydraulic fluid if it's low. * Ensure the fuel tanks are full.
  • B
    bennettmelodyAug 17, 2025
    How to fix abnormal engine vibration on my BOXER 700HDX?
    • L
      Lori McdonaldAug 17, 2025
      If you notice abnormal engine vibration in your BOXER Compact Loader, check the engine mounting bolts and tighten them.
  • J
    Joseph FrederickAug 21, 2025
    What to do if the boom drops downward quickly and then stops on my BOXER Compact Loader?
    • T
      Teresa KempAug 21, 2025
      If the boom of your BOXER Compact Loader drops downward quickly and then stops when the engine is off, it could be due to leaking cylinder seals. Consider replacing the cylinder seals.
  • C
    Caleb PetersonOct 26, 2025
    What to do if the starter does not turn the engine over on my BOXER 700HDX Compact Loader?
    • G
      Gerald SanchezOct 26, 2025
      If the starter on your BOXER Compact Loader isn't turning the engine over, here are a few things to check: * Ensure the auxiliary hydraulics lever is in the neutral position. If it's in the Forward or Reverse position without a hydraulically powered attachment, this could be the issue. Move the lever to the neutral position. * Check the battery. If it's dead, charge it. If the battery doesn't hold a charge, it may need to be replaced. * Inspect electrical connections. Corroded or loose connections can prevent the starter from working. Clean the battery terminals and cable clamps, and replace the connectors if they cannot be properly cleaned. * If the engine is in a hydraulic lock due to a cylinder filled with fuel, allow the engine to cool, then remove the fuel injectors and turn ...
  • T
    Tonya BennettOct 30, 2025
    What to do if my BOXER 700HDX Compact Loader engine will not start?
    • T
      thorntonvirginiaOct 30, 2025
      If your BOXER Compact Loader's engine won't start, starts hard, or fails to keep running, consider the following: * Ensure the auxiliary hydraulics lever is in the neutral position, especially if a hydraulically powered attachment is installed. Move the lever to neutral position. * Check the fuel level. If the fuel tanks are empty, fill them with diesel fuel. * Try cycling the glow plugs for about 10 seconds to help start the engine. * Inspect the air cleaner. If it's dirty, clean the air filter housing and replace the filter elements. * Check the fuel system. If there is dirt, water, or stale fuel, drain the fuel tanks into an appropriate storage container and dispose of the bad fuel properly. Refill with fresh, clean fuel and replace the fuel filter. * If the 30 Amp fuse is ...
