BOXER 700HDX - Operating Controls

Operating Controls
2.5
Operating Controls
Item No. Description
1 Engine coolant temperature gauge
2 Engine oil pressure gauge
3 Ignition switch
4 Ignition key
5 Track widen control
6 Right joystick
7 Left joystick
8 Engine throttle
9 Access panel Lock Levers
10 Lower service access panel
2
9
10
1
6
3
4
7
5
8
