BOXER 700HDX - Section 6 - General Specifications

6.1
Section 6 - General Specications
Engine System
Type
Kubota D1105-E4B
Cooling System
Liquid Cooled
HP
24.8
Engine System - Intake
Normally Aspirated
Fuel Tank
4.5 Gallons (17-litre) per tank
Air Cleaner
Heavy-Duty Air Cleaner
Hydraulic System
Oil Cooling System
Air to oil cooler with electric fan
Pressure (Auxiliary/Boom & Tilt Cylinder
Circuit)
3000 psi (20684 kPa) system relief
Pressure Ground Drive Circuit
2600 psi (17926 kPa) system relief
Flow Auxiliary
14.5 GPM
Flow Ground Drive
Variable Flow 0 - 14.5 GPM
Reservoir Capacity
20 Gallons (76-litres)
Filter
10 Micron
Electrical System
Battery
12 Volt DC
Control System
Starting
Keyed ignition switch.
Steering
Two spring centered control lever with zero
turning type controls.
Boom/Loader Arms
Four position, spring centered lever
control. Up, neutral, down, and oat.
Bucket/Attachment Tilt
Three position, spring centered lever
control. Extend, neutral, and curl.
Auxiliary/Attachment Control
Three position, detent lever control.
Wheel/Track Options
9” (230mm) wide track with variable width
undercarriage from 34.5” - 43.5” (88 cm -
110.5 cm)
Drive Train
Douoble Gear Pump
Creep Control
Variable
Operator Platform
Spring Cushioned Stand On Platform
Mount Plate
Universal CUL Attachment Plate
Warranty
Engine Warranty
Two Year
Product Warranty
One Year
Ground Drive System-Dimensions
Units English Metric
Wheelbase
37 in. 940 mm
Ground Clearance
5.0 in. 127 mm
Overall Length (w/ Bucket)
96 in. 2440 mm
Overall Length (without Bucket)
77 in. 1956 mm
Overall Width (Fully Retracted)
35 in. 876 mm
Overall Width (Fully Extended)
43.5 in. 1105 mm
Overall Height
54 in. 1360 mm
Overall Operating Height (Fully Raised)
98 in. 2489 mm
